The Dazzle III is a LED video wall display which has the capabilities to be a flat screen, or to curve at 5° in either a concave or convex formation; making creative options with this screen endless. With a 2.6mm pixel pitch, the Dazzle III LED Video screen is the perfect high resolution solution for all events.


Model Name: IDA III 2.6

Pixel Pitch: 2.604mm

Pixel Density: 146456pixel/㎡

Brightness: 1000cd/m2

Panel Dimension: (W×H×D): 500mm×500mm×75mm

Panel Resolution: 192*192pixel

Panel Weight: 9.6kg

Max Cabinet Power Consumption: 184w

Average Cabinet Power Consumption: 55.2w

Viewing Angle: H:160º V:120º

Refresh Rate: 1920Hz

Gray Scale: 14-18bit

Waterproof Level: IP20

Operating Temperature: -20℃~+40℃

Max. Stacking 25pcs

Max. Hanging 20pcs

Life Span 50,000hrs
